MODEL · FT308GPS-2G
10-Port PoE Gigabit Industrial Switch
F-tone Networks 10-port PoE gigabit industrial switch, 20Gbps backplane, 48-56VDC, 30W max PoE out, ambient -20 to 70C. Ask Betty or Una for a quote now.
- Part Number
- FT308GPS-2G
- 网络接口
- l10个10/100/1000M FJ45端口
- 性能规范
- lMAC地址表：2k l背板带宽：20Gbps l包转发率：14.9Mpps l转发模式：存储转发
- 电源支持
- l输出最大功率：30W l电压输入：48-56V DC l输入方式：插拔式5芯5.08mm 间距接线端子
- LED指示灯
- l电源指示灯：P1,P2 l网口指示灯：Link&Act1-8,PoE1-8
- 环境规范
- l工作温度：-20-70℃ l存储湿度：-40-85℃ l相对湿度：5%-95%（非冷凝）
Reference model FT308GPS-2G in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| Part Number | FT308GPS-2G |
|---|---|
| 网络接口 | l10个10/100/1000M FJ45端口 |
| 性能规范 | lMAC地址表：2k l背板带宽：20Gbps l包转发率：14.9Mpps l转发模式：存储转发 |
| 电源支持 | l输出最大功率：30W l电压输入：48-56V DC l输入方式：插拔式5芯5.08mm 间距接线端子 |
| LED指示灯 | l电源指示灯：P1,P2 l网口指示灯：Link&Act1-8,PoE1-8 |
| 环境规范 | l工作温度：-20-70℃ l存储湿度：-40-85℃ l相对湿度：5%-95%（非冷凝） |
| 网络协议 | lIEEE802.3、IEEE802.3i、IEEE802.3u、IEEE802.3ab、IEEE802.3af/at |
| 经营 | l2L+ |
| 防静电 | l±8kV(contact),±15kV (air) |
| 尺寸（W*D*H） | l150*127*40mm |
Overview
Product details
Ten RJ45 gigabit ports with PoE feed industrial cameras and access points from a compact DIN-style body. Store-and-forward switching, 2K MAC, 20 Gbps backplane and 14.9 Mpps forwarding. PoE budget peaks at 30 W from 48-56 VDC on a 5-pin 5.08 mm terminal.
Key Features
- 10x 10/100/1000M RJ45 ports
- PoE IEEE 802.3af/at class
- 20 Gbps backplane, 14.9 Mpps
- 48-56 VDC input, 30 W PoE max
- Operating -20 to 70 C
Applications
- Industrial PoE camera edges
- Gigabit DIN-rail PoE closets
Specifications
| Parameter | Value |
|---|---|
| Part Number | FT308GPS-2G |
| Network Interfaces | 10x 10/100/1000M RJ45 |
| MAC Table | 2K |
| Backplane Bandwidth | 20 Gbps |
| Packet Forwarding | 14.9 Mpps |
| Forwarding Mode | Store-and-forward |
| PoE Max Output | 30 W |
| Voltage Input | 48-56 V DC |
| Power Connector | Pluggable 5-pin 5.08 mm |
| Operating Temperature | -20 to 70 C |
| Storage Temperature | -40 to 85 C |
| Relative Humidity | 5%-95% non-condensing |
| ESD | +/-8 kV contact, +/-15 kV air |
| Dimensions (W×D×H) | 150 x 127 x 40 mm |
| Protocols | IEEE 802.3 / 802.3i / 802.3u / 802.3ab / 802.3af/at |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| FT308GPS-2G | F-tone part number |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
