1 / 2Single-Mode High Temperature PTFE Jacket Multicore Sensor Cable
F-tone Networks FT-517: high temperature PTFE jacket sensor cable for fiber temperature sensing, rated for 150 C, G652D single-mode or 50/62.5 multimode.
- Features Has the characteristics of high temperature resistance, can be used in high temperature environment of communication and temperature monitoring. High strength fiber optic cable tensile and compressive properties. Has good environmental adaptation performance, can endure high low temperature difference.
- Application Used for optical fiber temperature sensing system Used for 150 ℃ high temperature environment
- Package 1
- Package 2
- Item
- G652D
- MM 50
- MM 62.5
- Core Diameter(µm)
- 9.2±0.4
- 50±2.5
- 62.5±2.5
Reference model FT-517 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Features Has the characteristics of high temperature resistance, can be used in high temperature environment of communication and temperature monitoring. High strength fiber optic cable tensile and compressive properties. Has good environmental adaptation performance, can endure high low temperature difference. | Application Used for optical fiber temperature sensing system Used for 150 ℃ high temperature environment |
|---|---|
| Package 1 | Package 2 |
| Item | G652D |
| MM 50 | MM 62.5 |
| Core Diameter(µm) | 9.2±0.4 |
| 50±2.5 | 62.5±2.5 |
| Cladding Diameter (µm) | 124.8±0.7 |
| 124.8±0.1 | 124.8±0.1 |
| Cladding Non-circularity(%) | ≤0.7 |
| ≤1.0 | ≤1.0 |
| Core-cladding Concentricity Error (µm) | ≤0.5 |
| ≤1.5 | ≤1.5 |
| Coating Diameter(µm) | 245±5 |
| 245±7 | 245±7 |
| Coarting-cladding Concentricity Error (µm) | ≤12.0 |
| ≤12.0 | ≤12.0 |
| Zero Dispersion Wavelength(nm) | 1302-1322 |
| 1295-1320 | 1320-1365 |
| Zero Dispersion Slop [ps/(nm2.km)] | ≤0.090 |
| ≤0.101 | ≤0.097 |
| Ngroup Index Of Refraction | 1310nm | 1550nm | 850nm | 1300nm | 850nm | 1300nm |
| 1.467 | 1.4677 |
| 1.481 | 1.476 |
| 1.496 | 1.491 |
| Singlemode | Multimode |
| Fiber core/Modal Diameter | µm | 9.2±0.4 | 50.0±2.5 | 62.5±2.5 |
| Cladding Diameter | µm | 125.0±1.0 | 125.0±1.0 | 125.0±1.0 |
| Attenuation | dB/km | 0.4dB/km@1310nm | 3.5dB/km@850nm | 3.5dB/km@850nm |
| 0.3dB/km@1550nm | 1.5dB/km@1300nm | 1.5dB/km@1300nm |
| Working Temperature | ℃ | -60℃~+85℃ |
| Cable shape | mm | 2.85±0.10 |
| Cable weight | Kg/km | 18 |
| Allowable Bending Radius | mm | Dynamic 20D Static 10D |
| Allow Tension | N | Long-term 200 Short-term 400 |
| Crush | N | Long-term 800 Short-term 1000 |
Product details
The FT-517 from F-tone Networks is a high-temperature multicore sensor cable with a Teflon (PTFE) jacket for optical fiber temperature sensing systems. The PTFE jacket tolerates sustained exposure to 150 degree C environments while the cable retains high tensile and compressive strength and stable performance across wide temperature swings. Available in G652D single-mode as well as 50/125 and 62.5/125 multimode fiber, it is built for distributed temperature sensing in industrial plants, furnaces and other hot environments where standard jackets would fail.
Key Features
- Multicore sensor cable with Teflon (PTFE) jacket
- Rated for 150 degree C high-temperature environments
- Built for optical fiber temperature sensing systems
- High tensile and compressive strength
- Fiber options: G652D single-mode, 50/125 and 62.5/125 multimode
- Stable performance across wide temperature swings
Applications
- Distributed temperature sensing in hot industrial zones
- Furnace and boiler monitoring
- Power plant and petrochemical sensing runs
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
