1 km ODC to ODC 2-Core Outdoor Armored Tactical Fiber Patch Cable

The FT-427 from F-tone Networks is a 1 km ODC-to-ODC 2-core outdoor armored tactical fiber patch cable for harsh field deployment. Both ends use rugged ODC connectors with a full ceramic ferrule and sleeve in nickel-plated brass. The ODC plug withstands ≤1000 N tensile load and ≤30 N static side load, the socket ≤30 N tensile load, with 1000 rated mating cycles. It spans -40 °C to +85 °C with IP68 sealing when mated, and passes 30-day salt mist, 10–500 Hz / 10 g vibration and 100 g shock per IEC 61300 series tests. Typical insertion loss is ≤0.30 dB (97% ≤0.45 dB) for single-mode with return loss ≥50 dB, a dependable field link for outdoor runs.

Key Features

• 1 km length, ODC rugged connector to ODC, 2-core outdoor armored construction
• Full ceramic ferrule and sleeve; nickel-plated brass housing
• ODC plug: ≤1000 N tensile load, ≤30 N static side load; 1000 mating cycles
• Operating temperature -40 °C to +85 °C; mated ingress protection IP68
• Passes 30-day salt mist, 10–500 Hz / 10 g vibration and 100 g shock
• Typical insertion loss ≤0.30 dB; single-mode return loss ≥50 dB

Applications

• Outdoor FTTx and field network deployment
• Temporary and event broadcast fiber links
• Military and emergency field communications
• Industrial sites with harsh environmental conditions
