10G BiDi XFP 1330/1270nm 20km Transceiver

A single-fiber XFP transceiver that sends at 1330nm and receives at 1270nm, so one strand of single-mode fiber carries both directions of a 10G link. It runs at up to 11.1Gbps over 20km, using a 1330nm DFB laser and a PIN receiver behind a simplex LC port. Transmit power is -3.0 to +2.0dBm and receive sensitivity better than -14.5dBm. Install it opposite a unit with the reverse wavelength pair; coded versions for several switch brands are available.

Key Features

• 11.1Gbps maximum data rate in XFP format
• TX 1330nm / RX 1270nm on one simplex LC fiber
• 20km reach over single-mode fiber
• 1330nm DFB transmitter with PIN receiver
• TX power -3.0 to +2.0dBm; RX sensitivity below -14.5dBm
• MSA compliant; selectable temperature grade

Applications

• Fiber-saving 10G access and aggregation links
• Metro Ethernet aggregation on XFP ports
• Halving fiber use on leased dark fiber

Specifications

Ordering References

Model and part numbers for ordering reference:
