1 / 510G XFP 1550nm 10km SDH/PDH Transceiver
F-tone Networks XFP for 10G SDH/PDH links at 1550nm: 10km over single-mode fiber, EML laser, PIN receiver, -3 to +4dBm launch, -15dBm sensitivity, multi-rate.
- Form Factor
- XFP
- Data Rate
- 10G
- Wavelength
- 1550nm
- 光器件
- EML/PIN
- 发光范围
- -3~+4dBm
- 收端灵敏度
- -15dBm
Reference model FT-XFP-10G-LR-1550 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Form Factor | XFP |
|---|---|
| Data Rate | 10G |
| Wavelength | 1550nm |
| 光器件 | EML/PIN |
| 发光范围 | -3~+4dBm |
| 收端灵敏度 | -15dBm |
| 接口 | LC |
| 工作温度范围 | 商业级/工业级/军品级可选 |
| Distance | 10KM |
| 多速率兼容 | Y |
Product details
Packaged as an XFP, this 1550nm optic covers 10km of single-mode fiber for SDH/PDH services. Its electro-absorption modulated laser sends -3 to +4dBm, and a PIN photodiode accepts down to -15dBm. Source data marks this part as multi-rate, which differs from the SFP+ equivalent. Temperature grade is picked when ordering, and the optical port is LC.
Key Features
- 1550nm XFP, 10km
- EML/PIN optics
- Launch -3 to +4dBm
- Sensitivity -15dBm
- Multi-rate, LC
Applications
- SDH/PDH transport on XFP shelves
- Telecom access and metro
- Short 1550nm links
Specifications
| Parameter | Value |
|---|---|
| Form Factor | XFP |
| Data Rate | 10G |
| Wavelength | 1550nm |
| Laser / Detector | EML/PIN |
| Output Power | -3~+4dBm |
| Receiver Sensitivity | -15dBm |
| Connector | LC |
| Operating Temperature | Commercial, industrial or military grade (selectable) |
| Reach | 10KM |
| Multi-rate Support | Yes |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
