1 / 510G CWDM XFP 1270–1370nm 40km Transceiver
40km 10G CWDM XFP for Ethernet from F-tone Networks: 1270 to 1370nm channels, DFB laser, PIN receiver, -6 to +1dBm output, -14.4dBm sensitivity, LC connector.
- Form Factor
- XFP
- Data Rate
- 10G
- Wavelength
- 1270~1370nm
- 光器件
- DFB/PIN
- 发光范围
- -6~+1dBm
- 收端灵敏度
- -14.4dBm
Reference model FT-XFP-10G-40KM-1371 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Form Factor | XFP |
|---|---|
| Data Rate | 10G |
| Wavelength | 1270~1370nm |
| 光器件 | DFB/PIN |
| 发光范围 | -6~+1dBm |
| 收端灵敏度 | -14.4dBm |
| 接口 | LC |
| 工作温度范围 | 商业级/工业级/军品级可选 |
| Distance | 40KM |
| 多速率兼容 | Y |
Product details
Covering 40km on channels from 1270 to 1370nm, this Ethernet CWDM XFP uses DFB/PIN optics with -6 to +1dBm output and -14.4dBm sensitivity. It lets XFP-equipped platforms join a CWDM network without hardware changes. Specify the channel to match your mux port. LC connection, multi-rate support and commercial, industrial or military temperature grades are available.
Key Features
- 40km CWDM
- 1270-1370nm channels
- Output -6 to +1dBm
- Sensitivity -14.4dBm
- DFB/PIN; LC; multi-rate
Applications
- Metro CWDM on XFP routers
- Linking regional offices
- Service provider aggregation
Specifications
| Parameter | Value |
|---|---|
| Form Factor | XFP |
| Data Rate | 10G |
| Wavelength | 1270~1370nm |
| Laser / Detector | DFB/PIN |
| Output Power | -6~+1dBm |
| Receiver Sensitivity | -14.4dBm |
| Connector | LC |
| Operating Temperature | Commercial, industrial or military grade (selectable) |
| Reach | 40KM |
| Multi-rate Support | Yes |
