1 / 710G XFP ER 1310nm 40km Transceiver
10G XFP ER module from F-tone Networks: 1310nm DFB, PIN receiver, 40km on single-mode duplex LC fiber, TX 0 to +4.0dBm, up to 11.1Gbps. Contact Betty or Una.
- Part Number
- XFP-10G31-ER
- Manufacturer
- F-tone
- Form Factor
- XFP
- Data Rate
- 11.1Gbps
- Wavelength
- 1310nm
- Max Distance
- 40km
Reference model FT-XFP-10G31-ER in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Part Number | XFP-10G31-ER |
|---|---|
| Manufacturer | F-tone |
| Form Factor | XFP |
| Data Rate | 11.1Gbps |
| Wavelength | 1310nm |
| Max Distance | 40km |
| Connector Type | 双工 LC |
| Transmitter Type | 1310nm DFB |
| Cable Type | 单模(SMF) |
| Receiver Type | PIN |
| TX Power | 0~+4.0dBm |
| RX Sensitivity | <-16.0dBm |
| Protocol | MSA Compliant |
| Operating Temperature | 商业级/工业级/军品级可选 |
| 光器件 | DFB/PIN |
| 多速率兼容 | N |
| XFP-10G85-3M | 9.95~11.1G |
| XFP-10G31-2M | 9.95~11.1G |
| XFP-10G31-2 | 9.95~11.1G |
| XFP-10G31-10 | 9.95~11.1G |
| XFP-10G31-20 | 9.95~11.1G |
| XFP-10G31-40 | 9.95~11.1G |
| XFP-10G31-70 | 9.95~11.1G |
| XFP-10G55-40 | 9.95~11.1G |
| XFP-10G55-80 | 9.95~11.1G |
| XFP-10G55-100 | 9.95~11.1G |
| XFP-10G55-120 | 9.95~11.1G |
Product details
An extended-reach XFP optic for 40km single-mode links, operating at 1310nm and up to 11.1Gbps. It pairs a 1310nm DFB transmitter with a PIN receiver; launch power is 0 to +4.0dBm and sensitivity is better than -16.0dBm, which gives room for longer metro spans. The duplex LC port and MSA compliance make it a drop-in choice for XFP line cards, with commercial, industrial or military temperature grades available.
Key Features
- 40km single-mode reach
- 1310nm DFB laser and PIN detector
- Launch power 0 to +4.0dBm
- Receive sensitivity better than -16.0dBm
- Up to 11.1Gbps, MSA compliant
- Duplex LC interface
Applications
- Metro and regional 10G Ethernet links
- Inter-office trunks for carriers
- Long campus backbones on XFP hardware
Specifications
| Parameter | Value |
|---|---|
| Form Factor | XFP |
| Data Rate | 11.1Gbps |
| Wavelength | 1310nm |
| Reach | 40km |
| Connector Type | Duplex LC |
| Transmitter Type | 1310nm DFB |
| Cable Type | Single-mode fiber (SMF) |
| Receiver Type | PIN |
| TX Power | 0~+4.0dBm |
| RX Sensitivity | <-16.0dBm |
| Protocol | MSA Compliant |
| Operating Temperature | Commercial, industrial or military grade (selectable) |
| Laser / Detector | DFB/PIN |
| Multi-rate Support | No |
| Compatible Brands | Adva / Nec |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| XFP-10G31-ER | F-tone part number |
| XFP-10G85-3M | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-2M | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-2 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-10 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-20 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-40 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G31-70 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G55-40 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G55-80 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G55-100 | Data rate (Gbps): 9.95~11.1G |
| XFP-10G55-120 | Data rate (Gbps): 9.95~11.1G |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
