10G Multi-rate XFP 1310nm 20km Transceiver

This multi-rate XFP module covers 20km of single-mode fiber at 1310nm and supports line rates up to 11.1Gbps. A DFB laser and PIN photodiode sit behind a duplex LC interface, with transmit power of -3.0 to +2.0dBm and receive sensitivity better than -15.0dBm. It is MSA compliant and can be built to commercial, industrial or military temperature grade. The ordering table also lists the wider XFP and multi-rate XFP family for other reaches.

Key Features

• Data rate up to 11.1Gbps
• 1310nm DFB laser, PIN receiver
• 20km over single-mode fiber, duplex LC
• TX -3.0 to +2.0dBm; RX sensitivity under -15.0dBm
• MSA compliant XFP
• Temperature grade chosen at order

Applications

• 10G Ethernet and OTN-rate links between buildings
• Router and switch uplinks across a campus
• Ports that must run more than one 10G line rate

Specifications

Ordering References

Model and part numbers for ordering reference:
