155M 1x9 SC Pigtail Single-Mode Optical Transceiver, 20km

Overview

The FT-155M-12 is a 155 Mbps 1x9 pigtail-style single-mode optical transceiver terminated with an SC connector, designed for 20 km links over single-mode fiber at 1310 nm. The pigtail form factor suits panel-mounted and space-constrained installations. Powered by a 3.3 V supply with an LVPECL signal interface, it serves SONET/SDH STM-1, Fast Ethernet and ATM equipment. Commercial (0 to 70 degC) and industrial (-40 to 85 degC) temperature versions are available, and the metal shield with plastic housing construction meets EMC Class A requirements. Customizable metallized connectors are available on request from F-tone Networks.

Key Features

• 155 Mbps data rate, 1x9 pigtail form factor with SC optical connector
• 1310 nm wavelength, 20 km reach over single-mode fiber
• 3.3 V supply voltage, LVPECL signal level (LVPECL-SD: LVTTL)
• Commercial 0 to 70 °C and industrial -40 to 85 °C temperature options
• Metal shield with plastic housing, EMC Class A compliant
• Customizable metallized connectors available on request

Applications

• SONET/SDH STM-1 transmission links
• Fast Ethernet and ATM network equipment
• Panel-mounted and space-constrained installations
• Telecom central office and access network systems

Specifications
