1 / 3MODEL · FT-BIDI-9
84Mbps 1x9 BiDi Optical Transceiver, ST, SM 20 km
F-tone Networks FT-BIDI-9: 84Mbps 1x9 BiDi single-fiber transceiver, ST connector, 1310/1550 nm, 20 km reach, 3.3V/5V supply, LVTTL/TTL for access networks.
- 产品型号 Product Model
- 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
- FT-WY352-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY532-**
- 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY354-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY534-**
- 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY356-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
Reference model FT-BIDI-9 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| 产品型号 Product Model | 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃) |
|---|---|
| FT-WY352-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY532-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY354-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY534-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY356-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY536-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY458-** | 84Mbps | SC/FC/ST | BIDI | SM 1490nm | 80KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY548-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 80KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY45X-** | 84Mbps | SC/FC/ST | BIDI | SM 1490nm | 100KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY54X-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 100KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| 产品型号Product Model | 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃) |
Overview
Product details
The FT-BIDI-9 is an 84 Mbps bidirectional 1x9 optical transceiver terminated with an ST connector for single-fiber, single-mode links. The 1310 nm / 1550 nm wavelength pair delivers 20 km of reach while using only one fiber strand, a practical fit for access networks where fiber is scarce. It accepts 3.3 V or 5 V supplies with LVTTL/TTL signaling and comes in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature versions for indoor and outdoor equipment.
Key Features
- 84 Mbps BiDi over one single-mode fiber strand
- ST connector; 1310 nm / 1550 nm wavelength pair
- 20 km reach
- 3.3 V / 5 V supply; LVTTL/TTL levels
- 0 to 70 °C commercial and -40 to 85 °C industrial grades
Applications
- FTTH/FTTB access networks
- Campus single-fiber links
- Utility telemetry networks
- Legacy transmission platforms
Specifications
| Parameter | Value |
|---|---|
| Part Number | FT-BIDI-9 |
| Form Factor | 1x9 |
| Data Rate | 84 Mbps |
| Type | BiDi (single fiber) |
| Connector | ST (SC/FC available in series) |
| Fiber Type | Single-mode (SM) |
| Wavelength | 1310 nm / 1550 nm (BiDi pair) |
| Distance | 20 km |
| Supply Voltage | 3.3 V / 5 V |
| Signal Level | LVTTL / TTL |
| Operating Temperature | 0 to 70 °C (commercial); -40 to 85 °C (industrial) |
Series Variants
| Variant | Wavelength | Distance |
|---|---|---|
| FT-WY352 | 1310 nm | 20 km |
| FT-WY532 | 1550 nm | 20 km |
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
