2Mbps 1x9 ST BIDI Single-Mode Optical Transceiver, 20km

Overview

The FT-BIDI-3 is a 2 Mbps 1x9 optical transceiver for single-fiber bidirectional transmission, letting transmit and receive signals share one fiber. With an ST bayonet-locking connector, it operates over single-mode fiber at 1310 or 1550 nm and covers distances up to 20 km. The module accepts 3.3 V or 5 V power and uses LVTTL or TTL signal levels for straightforward integration with industrial control electronics. Commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature versions support both indoor racks and harsh outdoor cabinets. The FT-BIDI-3 is a practical choice for operators that need to double fiber capacity on existing low-speed links.

Key Features

• 2 Mbps data rate with single-fiber bidirectional (BIDI) transmission
• ST bayonet-locking optical connector, single-mode fiber
• 1310 nm or 1550 nm wavelength options
• Up to 20 km reach over standard single-mode fiber
• 3.3 V / 5 V supply with LVTTL / TTL signal level
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) versions

Applications

• Industrial Ethernet and fieldbus optical links
• Fiber access and point-to-point optical backhaul
• Telecom and utility networks with limited fiber resources

Specifications

The FT-BIDI series also offers FC and SC connector versions with 20 km and 40 km reaches.
