155M 1x9 BIDI ST Optical Transceiver 20km

Overview

The FT-BIDI-13 is a 155 Mbps 1x9 bidirectional optical transceiver that carries both directions of traffic over a single single-mode fiber. It uses the bayonet ST connector, operates at 1310 nm, and supports links up to 20 km, making it a practical choice for doubling capacity on fiber-scarce routes. The module is supplied from 3.3 V with an LVPECL signal interface and uses a metal-shielded package designed to meet EMC-CLASS A requirements. Temperature options of 0 to 70 °C commercial and -40 to 85 °C industrial cover both indoor racks and outdoor installations. It is used together with a complementary module at the remote end.

Key Features

• 155 Mbps bidirectional transmission over one single-mode fiber strand
• ST connector, 1310 nm wavelength, up to 20 km reach
• 3.3 V supply with LVPECL signal interface
• Metal-shielded package designed to meet EMC-CLASS A requirements
• Operating temperature: 0 to 70 °C commercial, -40 to 85 °C industrial

Applications

• Fiber-scarce access networks needing single-fiber links
• SDH STM-1 / SONET OC-3 point-to-point connections
• Industrial backbones and remote monitoring links

Specifications
