84Mbps 1x9 BiDi Optical Transceiver, ST, SM 40 km
F-tone Networks FT-BIDI-10: 84Mbps 1x9 BiDi single-fiber transceiver, ST connector, 1310/1550 nm, 40 km reach, 3.3V/5V supply, LVTTL/TTL for access networks.
- 产品型号 Product Model
- 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
- FT-WY352-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY532-**
- 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY354-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY534-**
- 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-WY356-**
- 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
Reference model FT-BIDI-10 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| 产品型号 Product Model | 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃) |
|---|---|
| FT-WY352-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY532-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 20KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY354-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY534-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 40KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY356-** | 84Mbps | SC/FC/ST | BIDI | SM 1310nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY536-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 60KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY458-** | 84Mbps | SC/FC/ST | BIDI | SM 1490nm | 80KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY548-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 80KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY45X-** | 84Mbps | SC/FC/ST | BIDI | SM 1490nm | 100KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-WY54X-** | 84Mbps | SC/FC/ST | BIDI | SM 1550nm | 100KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
Product details
The FT-BIDI-10 is an 84 Mbps bidirectional 1x9 transceiver with an ST connector, built for 40 km single-fiber links. Operating on 1310 nm and 1550 nm wavelength pairs over single-mode fiber, it halves fiber consumption on point-to-point access and utility links. The 3.3 V / 5 V supply and LVTTL/TTL interface ease integration into legacy equipment, with commercial and industrial temperature grades covering indoor and harsh outdoor deployments. The single-strand design suits FTTx, utility telemetry, and industrial control networks where spare fiber is limited.
Key Features
- 84 Mbps BiDi single-fiber transmission, ST connector
- 1310 nm / 1550 nm wavelength pair; 40 km reach
- 3.3 V / 5 V supply; LVTTL/TTL interface
- Commercial (0 to 70 °C) and industrial (-40 to 85 °C) grades
Applications
- Medium-reach access networks
- Industrial and utility communication links
- Campus interconnects over existing single fiber
- Legacy transport equipment upgrades
Specifications
| Parameter | Value |
|---|---|
| Part Number | FT-BIDI-10 |
| Form Factor | 1x9 |
| Data Rate | 84 Mbps |
| Type | BiDi (single fiber) |
| Connector | ST (SC/FC available in series) |
| Fiber Type | Single-mode (SM) |
| Wavelength | 1310 nm / 1550 nm (BiDi pair) |
| Distance | 40 km |
| Supply Voltage | 3.3 V / 5 V |
| Signal Level | LVTTL / TTL |
| Operating Temperature | 0 to 70 °C (commercial); -40 to 85 °C (industrial) |
Series Variants
| Variant | Wavelength | Distance |
|---|---|---|
| FT-WY354 | 1310 nm | 40 km |
| FT-WY534 | 1550 nm | 40 km |
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
