622M 1x9 ST Single-Mode Transceiver, 1310nm, 20km

Overview

The FT-622M-10 is a 622 Mbps 1x9 optical transceiver module with an ST receptacle interface for single-mode spans up to 20 km, built for STM-4/OC-12 SDH/SONET links and industrial field equipment using the bayonet-lock ST connector. It operates at 1310 nm with LVPECL signal levels on a 3.3 V supply, suiting metro access and plant-floor aggregation links. Commercial (0 to 70 °C) and industrial (-40 to 85 °C) grades are available, plus a grounded FC/ST option rated -40 to 105 °C, in an EMC Class A metal shield housing. The single-mode 622M family spans 20 km to 100 km, with SC and FC connector options available.

Key Features

• 622 Mbps data rate in a 1x9 pin package
• ST receptacle interface for single-mode fiber
• 1310 nm wavelength with up to 20 km reach
• 3.3 V supply with LVPECL signal levels
• Commercial 0 to 70 °C and industrial -40 to 85 °C grades; grounded FC/ST option to -40 to 105 °C
• EMC Class A metal shield housing; family covers 20 km to 100 km, with SC and FC options

Applications

• SDH/SONET STM-4/OC-12 transmission links
• Industrial field and plant-floor aggregation links
• Metro access single-mode connections
• Telecom access and aggregation networks

Specifications
