155M 1x9 ST Single-Mode Optical Transceiver, 60-120km

Overview

The FT-155M-16 is a 155 Mbps 1x9 single-mode optical transceiver with an ST connector, designed for long-reach STM-1/OC-3, Fast Ethernet and Fibre Channel links. The series transmits at 1310 nm for 60 km spans (FT-S1136) and at 1550 nm for 80 km (FT-S1158), 100 km (FT-S115X) and 120 km (FT-S115Y) spans. It runs on a single 3.3 V supply with an LVPECL electrical interface and LVTTL signal detect, and is offered in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades. EMC Class A shielding, a metallic shield with plastic housing, keeps the link stable in electrically noisy industrial environments.

Key Features

• 155 Mbps full-duplex 1x9 transceiver for STM-1/OC-3, Fast Ethernet and 100M Fibre Channel
• ST connector, single-mode fiber: 60 km @ 1310 nm; 80, 100 and 120 km @ 1550 nm
• Single 3.3 V supply; LVPECL electrical interface with LVTTL signal-detect output
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades
• EMC Class A: metallic shield with plastic housing
• Grounded industrial-grade (-40 to +105 °C) and dual-chip 5 V versions per factory specification

Applications

• SDH/SONET STM-1/OC-3 long-haul transmission
• Telecom access and metro backbone links up to 120 km
• Fast Ethernet and ATM long-distance backbones
• Industrial networks requiring high-EMC optical links

Specifications
