155M 1x9 ST Single-Mode Optical Transceiver, 40km

Overview

The FT-155M-14 is a 155 Mbps 1x9 single-mode optical transceiver with an ST connector, built for 40 km reaches over single-mode fiber at 1310 nm. A 3.3 V supply with an LVPECL signal interface provides stable low-rate optical transmission for SONET/SDH STM-1, Fast Ethernet and ATM networks. The module comes in commercial (0 to 70 degC) and industrial (-40 to 85 degC) temperature versions, and its metal shield with plastic housing construction meets EMC Class A requirements. Customizable ST metallized connectors are available on request from F-tone Networks.

Key Features

• 155 Mbps data rate, 1x9 package with ST optical connector
• 1310 nm wavelength, 40 km reach over single-mode fiber
• 3.3 V supply voltage, LVPECL signal level (LVPECL-SD: LVTTL)
• Commercial 0 to 70 °C and industrial -40 to 85 °C temperature options
• Metal shield with plastic housing, EMC Class A compliant
• Customizable metallized connectors available on request

Applications

• SONET/SDH STM-1 transmission links
• Fast Ethernet and ATM network equipment
• Telecom central office and access network systems
• Industrial control and monitoring networks

Specifications

Contact

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
