1.25G MM BIDI 1x9 ST Multimode Optical Transceiver, 2km

Overview

The FT-1-25G-BIDI-9 is a 1.25 Gbps bidirectional transceiver in the 1x9 package, linking two points up to 2 km apart over a single multimode fiber strand. One direction rides on 1310 nm and the return on 1550 nm, so the module delivers full-duplex 1.25 Gbps with half the fiber of a duplex pair. The ST bayonet connector suits legacy multimode plants where ST patching is already installed. Operating from 3.3 V with an LVPECL signal interface, it drops into existing 1x9 sockets. Commercial (0 to 70 ℃) and industrial (-40 to 85 ℃) temperature grades cover both office and field deployments.

Key Features

• 1.25 Gbps full-duplex transmission over a single multimode fiber strand
• ST bayonet connector, 2 km reach with 1310 / 1550 nm wavelength windows
• 3.3 V supply with LVPECL signal interface
• Commercial (0 to 70 ℃) and industrial (-40 to 85 ℃) temperature grades
• Metal shield housing, EMC Class A design

Applications

• Legacy LAN upgrades over existing ST patching
• Single-fiber campus and building links
• Telecom access and wiring-closet deployments

Specifications
