FT-1-25G-550M-3 product image - F-tone Networks 1 / 2
MODEL · FT-1-25G-550M-3

1.25G 1x9 ST Multimode Optical Transceiver, 550m–2km

F-tone Networks FT-1-25G-550M-3: 1.25G 1x9 ST multimode transceiver. 850 nm for 550 m or 1310 nm for 2 km, 3.3 V/5 V LVTTL/TTL interface, two temp grades.

Optical Transceivers
Product Model
速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
FT-M2850–S*
1.25Gbps | SC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2130–S*
1.25Gbps | SC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2850–F*
1.25Gbps | FC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2130–F*
1.25Gbps | FC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2850–T*
1.25Gbps | ST | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
Request a quote WhatsApp Betty

Reference model FT-1-25G-550M-3 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓

Specifications

Technical parameters

Product Model速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
FT-M2850–S*1.25Gbps | SC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2130–S*1.25Gbps | SC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2850–F*1.25Gbps | FC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2130–F*1.25Gbps | FC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2850–T*1.25Gbps | ST | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
FT-M2130–T*1.25Gbps | ST | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
1. 接地工业级:-40~105°C(**FC/ST) 2. 2.过EMC-CLASS A(金属屏蔽罩+屏蔽外壳) 3. 3.LVPECL电平需第四脚TTL电平 4. 4.定制高品质FC/ST接头光模块(见上图) 5. 5.双芯片5V光模块 需要以上光模块，可咨询厂家1. Grounding industrialTemperature Range: -40°C to +105°C 2. EMC-CLASS A:Metallic shield and Plastic housing. 3.LVPECL-SD:LVTTL 4.Customizable FC/ST Metallized connector 5.5v Optical Modules For more information,please contactthe manufacturer!
Overview

Product details

Overview

The FT-1-25G-550M-3 is a 1.25 Gbps multimode 1x9 transceiver fitted with an ST bayonet connector, a natural fit for legacy multimode plants built on ST patching. Two wavelength options cover short reaches: 850 nm for up to 550 meters and 1310 nm for up to 2 km. The module works from either a 3.3 V or 5 V supply with an LVTTL/TTL signal interface, matching both new and older 1x9 host designs. Commercial (0 to 70 ℃) and industrial (-40 to 85 ℃) temperature grades are available, and a metal shield housing addresses EMC Class A requirements.

Key Features

  • 1.25 Gbps duplex transmission over multimode fiber
  • Two reach options: 850 nm for up to 550 m, 1310 nm for up to 2 km
  • ST bayonet connector, a natural fit for legacy ST patching plants
  • Dual supply: 3.3 V or 5 V, with LVTTL/TTL signal interface
  • Commercial (0 to 70 ℃) and industrial (-40 to 85 ℃) temperature grades
  • Metal shield housing, EMC Class A design

Applications

  • Legacy enterprise LAN upgrades over ST patching
  • Gigabit Ethernet building and campus links
  • Industrial networks and 1x9 equipment maintenance

Specifications

ParameterValue
Part NumberFT-1-25G-550M-3
Form Factor1x9
Data Rate1.25 Gbps
ConnectorST
Fiber TypeMultimode (duplex)
Wavelength / Distance850 nm up to 550 m; 1310 nm up to 2 km
Supply Voltage3.3 V / 5 V
Signal LevelLVTTL/TTL
Operating Temperature0 to 70 ℃ / -40 to 85 ℃
EMI ShieldingMetal shield housing, EMC Class A

Contact Us

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
