10Mbps BIDI SC 1x9 Optical Transceiver Module, Multimode 2km

Overview

The FT-BIDI-5 is a 10 Mbps single-fiber bidirectional 1x9 optical transceiver module with an SC receptacle, built for cost-efficient Fast Ethernet links over multimode fiber. It carries transmit and receive traffic on one fiber strand using wavelength-division multiplexing, pairing 1310 nm and 1550 nm wavelengths to reach up to 2 km. The 1x9 metal package suits legacy switches, media converters, and industrial equipment that use through-hole transceiver footprints. It runs from 3.3 V or 5 V supplies with LVTTL/TTL signal levels, and it is offered in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades for indoor and outdoor cabinet deployments.

Key Features

• 10 Mbps Fast Ethernet data rate with single-fiber bidirectional operation
• SC optical receptacle in a 1x9 through-hole metal package
• 1310 nm / 1550 nm WDM wavelength pair over multimode fiber
• 2 km maximum reach on multimode fiber
• 3.3 V or 5 V power supply with LVTTL/TTL electrical interface
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades

Applications

• Single-fiber Fast Ethernet access and aggregation links
• Campus backbones where installed fiber is limited
• Industrial control and factory automation networks
• Fiber-conserving metro and edge network extensions

Specifications
