2Mbps 1x9 SC BIDI Multi-Mode Optical Transceiver, 2km

Overview

The FT-BIDI-2 is a 2 Mbps 1x9 transceiver that sends and receives over a single multi-mode fiber, halving the fiber needed for each link. Equipped with an SC push-pull connector, it works at 1310 or 1550 nm and reaches up to 2 km on multi-mode fiber, fitting building and campus backbones. Power supply options are 3.3 V or 5 V with LVTTL or TTL signal levels, matching common industrial interfaces. Commercial (0 to 70 °C) and industrial (-40 to 85 °C) grades cover both controlled equipment rooms and extended-temperature enclosures. The FT-BIDI-2 suits cost-sensitive upgrades where existing multi-mode plant must carry more channels without new cabling.

Key Features

• 2 Mbps data rate over a single multi-mode fiber (BIDI)
• SC push-pull optical connector for fast installation
• 1310 nm or 1550 nm wavelength options
• Up to 2 km reach over multi-mode fiber
• 3.3 V / 5 V supply with LVTTL / TTL signal level
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) versions

Applications

• Industrial automation and control network links
• Building and campus optical backbones
• Fiber plant upgrades where new cabling is not an option

Specifications

The FT-BIDI series also offers FC and ST connector versions for single-mode fiber.
