84Mbps 1x9 Optical Transceiver, MM SC, 1310 nm 2 km
F-tone Networks FT-84M-4: 84Mbps 1x9 multimode transceiver with SC connector, 1310 nm, 2 km reach, 3.3V/5V supply, LVTTL/TTL for industrial control networks.
- 产品型号 Product Model
- 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
- FT-MY850–S*
- 84Mbps | SC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-MY130–S*
- 84Mbps | SC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-MY850–F*
- 84Mbps | FC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-MY130–F*
- 84Mbps | FC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
- FT-MY850–T*
- 84Mbps | ST | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃
Reference model FT-84M-4 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| 产品型号 Product Model | 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃) |
|---|---|
| FT-MY850–S* | 84Mbps | SC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-MY130–S* | 84Mbps | SC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-MY850–F* | 84Mbps | FC | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-MY130–F* | 84Mbps | FC | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-MY850–T* | 84Mbps | ST | MM | MM 850nm | 550M | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
| FT-MY130–T* | 84Mbps | ST | MM | MM 1310nm | 2KM | 3.3V/5V | LVTTL/TTL | 0℃~70℃ / -40℃~85℃ |
Product details
The FT-84M-4 is an 84 Mbps multimode 1x9 optical transceiver fitted with an SC connector. At 1310 nm it reaches 2 km over multimode fiber, suiting campus backbones, industrial networks, and legacy access platforms. The module accepts 3.3 V or 5 V supplies with LVTTL/TTL levels and is available in commercial and industrial temperature grades for varied deployment environments. The SC interface matches widely installed patch panels, and the 1x9 footprint allows direct replacement in existing line cards and media converters without board redesign.
Key Features
- 84 Mbps over multimode fiber, SC connector
- 1310 nm wavelength; 2 km reach
- 3.3 V / 5 V supply; LVTTL/TTL signaling
- Commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades
- Receptacle or pigtail optical interface
Applications
- Campus backbone networks
- Industrial Ethernet extensions
- Legacy access platforms
- Utility and transportation communication
Specifications
| Parameter | Value |
|---|---|
| Part Number | FT-84M-4 |
| Form Factor | 1x9 |
| Data Rate | 84 Mbps |
| Connector | SC (FC/ST available in series) |
| Fiber Type | Multimode (MM) |
| Wavelength | 1310 nm |
| Distance | 2 km |
| Supply Voltage | 3.3 V / 5 V |
| Signal Level | LVTTL / TTL |
| Operating Temperature | 0 to 70 °C (commercial); -40 to 85 °C (industrial) |
| Interface | Receptacle or pigtail optical interface |
Series Variants
| Variant | Wavelength | Distance |
|---|---|---|
| FT-MY850-S | 850 nm | 550 m |
| FT-MY130-S | 1310 nm | 2 km |
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
