622M 1x9 SC Multimode Transceiver, 850/1310nm, 550m/2km

Overview

The FT-622M-2 is a 622 Mbps 1x9 optical transceiver module with an SC receptacle interface, designed for multimode fiber links in SDH/SONET, ATM and Ethernet aggregation networks. It covers two multimode reach options: up to 550 m at 850 nm over standard 50/125 or 62.5/125 μm fiber, and up to 2 km at 1310 nm for longer building-to-building runs. The module operates on 3.3 V or 5 V with LVTTL/TTL signal levels, and is available in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades. A metal shield housing meets EMC Class A emissions requirements. SC, FC and ST connector variants are offered across the same 622M 1x9 family.

Key Features

• 622 Mbps data rate in a 1x9 pin package
• SC receptacle interface for multimode fiber
• 850 nm wavelength up to 550 m; 1310 nm wavelength up to 2 km
• 3.3 V / 5 V supply with LVTTL/TTL signal levels
• Commercial grade 0 to 70 °C and industrial grade -40 to 85 °C
• EMC Class A metal shield housing; SC, FC and ST connector variants in the same family

Applications

• SDH/SONET STM-4/OC-12 transmission links
• Telecom access and aggregation networks
• Campus and building backbone fiber links
• Industrial communication systems

Specifications
