2Mbps 1x9 SC Multi-Mode Optical Transceiver, 2km

Overview

The FT-2M-4 is a 2 Mbps 1x9 multi-mode transceiver with an SC connector, built for 2 km links over multi-mode fiber at 1310 nm. The SC push-pull interface speeds up installation in dense panels and field cabinets. It accepts 3.3 V or 5 V supply and LVTTL or TTL signal levels, and comes in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades. The FT-2M-4 fits factory automation, traffic control and building management networks that need stable low-speed optical connectivity.

Key Features

• 2 Mbps data rate over multi-mode fiber
• SC push-pull optical connector for fast installation
• 1310 nm wavelength
• Up to 2 km reach over multi-mode fiber
• 3.3 V / 5 V supply with LVTTL / TTL signal level
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) versions

Applications

• Factory automation and building management networks
• Traffic control and transportation systems
• Dense panel installations needing push-pull connectors

Specifications

The FT-2M series also offers FC and ST connector versions with 550 m and 2 km options.
