2Mbps 1x9 SC Single-Mode Optical Transceiver, 40km

Overview

The FT-2M-15 is a 2Mbps 1x9 optical transceiver module for single-mode fiber links, extending reach to 40km. It uses an SC push-pull connector and transmits at 1310nm, fitting long serial spans across campuses and industrial parks. The module works from a 3.3V or 5V supply with LVTTL/TTL signal levels, so it mounts directly onto existing serial boards. Commercial (0 to 70°C) and industrial (-40 to 85°C) temperature grades cover both telecom rooms and field enclosures. Its standard 1x9 footprint keeps mechanical integration straightforward for equipment built around 1x9 sockets.

Key Features

• 2Mbps data rate over single-mode fiber in a 1x9 package
• SC push-pull connector for fast, tool-free mating
• 1310nm wavelength, 40km transmission reach
• 3.3V or 5V supply voltage
• LVTTL/TTL electrical signal interface
• 0 to 70°C commercial and -40 to 85°C industrial temperature grades

Applications

• Long-span 2Mbps serial and E1/PDH links
• Metropolitan and inter-site telecom connections
• Campus and industrial park fiber backbones
• Utility and transportation communication networks

Specifications
