2Mbps 1x9 FC Single-Mode Optical Transceiver, 20km

Overview

The FT-2M-12 is a 2Mbps 1x9 optical transceiver module for single-mode fiber links. It uses an FC threaded connector with screw-type coupling for secure mating in vibration-prone cabinets, and transmits at 1310nm over distances of up to 20km. The module works from a 3.3V or 5V supply with LVTTL/TTL signal levels, fitting directly onto existing serial boards. Commercial (0 to 70°C) and industrial (-40 to 85°C) temperature grades cover both telecom rooms and field sites. The standard 1x9 footprint makes the FT-2M-12 a direct mechanical replacement for other 1x9 modules.

Key Features

• 2Mbps data rate over single-mode fiber in a 1x9 package
• FC threaded connector with screw-type coupling
• 1310nm wavelength, 20km transmission reach
• 3.3V or 5V supply voltage
• LVTTL/TTL electrical signal interface
• 0 to 70°C commercial and -40 to 85°C industrial temperature grades

Applications

• 2Mbps serial links and E1/PDH transmission equipment
• Telecom access and local-loop networks
• Industrial control and telemetry systems
• Security and surveillance fiber backbones

Specifications
