155M 1x9 FC Single-Mode Optical Transceiver, 60-120km

Overview

The FT-155M-7 is a 155 Mbps 1x9 single-mode optical transceiver with an FC connector, covering link distances from 60 to 120 km. The 60 km version operates at 1310 nm, while 80, 100 and 120 km versions use 1550 nm DFB lasers for extended reach. A 3.3 V supply with LVPECL signaling keeps power draw low, and commercial (0 to 70 degC) and industrial (-40 to 85 degC) temperature versions support deployment from equipment rooms to outdoor cabinets. Metal shield and plastic housing construction meets EMC Class A, and FC/ST metallized connectors can be customized on request from F-tone Networks.

Key Features

• 155 Mbps data rate, 1x9 package with FC optical connector
• 60 to 120 km reach: 1310 nm for 60 km; 1550 nm for 80/100/120 km
• 3.3 V supply voltage, LVPECL signal level (LVPECL-SD: LVTTL)
• Commercial 0 to 70 °C and industrial -40 to 85 °C temperature options
• Metal shield with plastic housing, EMC Class A compliant
• Customizable metallized connectors available on request

Applications

• Long-haul SONET/SDH STM-1 transmission links
• Fast Ethernet and ATM backbone equipment
• Inter-office and metro access network systems
• Industrial control and monitoring networks

Specifications
