155M 1x9 FC Single-Mode Optical Transceiver 40km
F-tone Networks FT-155M-5: 155 Mbps 1x9 FC single-mode optical transceiver, 1310 nm, 40 km reach, 3.3 V supply, LVPECL interface. For SDH/SONET access networks.
- 产品型号 Product Model
- 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃)
- FT-S1132-**
- 155Mbps | SC/FC/ST | SM | SM 1310 | 20km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃
- FT-S1134-**
- 155Mbps | SC/FC/ST | SM | SM 1310 | 40km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃
- FT-S1136-**
- 155Mbps | SC/FC/ST | SM | SM 1310 | 60km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃
- FT-S1158-**
- 155Mbps | SC/FC/ST | SM | SM 1550 | 80km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃
- FT-S115X-**
- 155Mbps | SC/FC/ST | SM | SM 1550 | 100km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃
Reference model FT-155M-5 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| 产品型号 Product Model | 速率Data Rate | 接头类型Port | 单多模Fiber | 波长Wave(nm) | 传输距离Distance (KM) | 电压Voltage | 信号电平Signal Level | 温度Temp. (℃) |
|---|---|
| FT-S1132-** | 155Mbps | SC/FC/ST | SM | SM 1310 | 20km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| FT-S1134-** | 155Mbps | SC/FC/ST | SM | SM 1310 | 40km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| FT-S1136-** | 155Mbps | SC/FC/ST | SM | SM 1310 | 60km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| FT-S1158-** | 155Mbps | SC/FC/ST | SM | SM 1550 | 80km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| FT-S115X-** | 155Mbps | SC/FC/ST | SM | SM 1550 | 100km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| FT-S115Y-** | 155Mbps | SC/FC/ST | SM | SM 1550 | 120km | 3.3V | LVPECL | 0℃~70℃ / -40℃~85℃ |
| 1. 接地工业级:-40~105°C(**FC/ST) 2. 2.过EMC-CLASS A(金属屏蔽罩+屏蔽外壳) 3. 3.LVPECL电平需第四脚TTL电平 4. 4.定制高品质FC/ST接头光模块(见上图) 5. 5.双芯片5V光模块 需要以上光模块，可咨询厂家 | 1. Grounding industrialTemperature Range: -40°C to +105°C 2. EMC-CLASS A:Metallic shield and Plastic housing. 3.LVPECL-SD:LVTTL 4.Customizable FC/ST Metallized connector 5.5v Optical Modules For more information,please contactthe manufacturer! |
Product details
Overview
The FT-155M-5 is a 155 Mbps 1x9 optical transceiver for longer single-mode access links. It pairs a threaded FC connector with a 1310 nm transmitter to reach up to 40 km over standard single-mode fiber, extending reach between central offices and remote sites without regeneration. The module runs from 3.3 V with an LVPECL signal interface in the classic 1x9 footprint and uses a metal-shielded package designed to meet EMC-CLASS A requirements. Commercial and industrial temperature options cover 0 to 70 °C and -40 to 85 °C. It fits SDH/SONET and Fast Ethernet over fiber deployments that need extra reach.
Key Features
- 155 Mbps data rate over single-mode fiber through an FC connector
- 1310 nm transmitter with up to 40 km transmission distance
- 3.3 V supply with LVPECL signal interface
- Metal-shielded package designed to meet EMC-CLASS A requirements
- Operating temperature: 0 to 70 °C commercial, -40 to 85 °C industrial
Applications
- SDH STM-1 / SONET OC-3 long-access links
- Carrier metro aggregation links
- Inter-office and remote-site fiber connections
Specifications
| Part Number | FT-155M-5 |
| Form Factor | 1x9 optical transceiver |
| Data Rate | 155 Mbps |
| Connector | FC |
| Fiber Type | Single-mode |
| Transmit Wavelength | 1310 nm |
| Transmission Distance | 40 km |
| Supply Voltage | 3.3 V |
| Signal Interface | LVPECL |
| EMI Shielding | Metal-shielded package, EMC-CLASS A design |
| Operating Temperature | 0 to 70 °C (commercial), -40 to 85 °C (industrial) |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
