10Mbps FC/ST 1x9 Optical Transceiver Module, Multimode 550m-2km

Overview

The FT-10M-3 is a 10 Mbps 1x9 optical transceiver module offered with threaded FC or bayonet ST coupling, giving field engineers flexibility to match existing patch panels. It supports 850 nm operation up to 550 m and 1310 nm operation up to 2 km over multimode fiber, covering both short intra-building runs and longer campus links. The 1x9 through-hole metal package suits legacy Fast Ethernet switches, media converters, and industrial control equipment. It runs from 3.3 V or 5 V supplies with LVTTL/TTL signal levels, and it is available in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades.

Key Features

• 10 Mbps Fast Ethernet data rate over multimode fiber
• Threaded FC or bayonet ST connector options in a 1x9 metal package
• 850 nm up to 550 m and 1310 nm up to 2 km
• 3.3 V or 5 V power supply with LVTTL/TTL signal levels
• Commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades
• One module family for mixed threaded and bayonet installed bases

Applications

• Mixed connector environments in campus and industrial networks
• Fast Ethernet backbone upgrades without re-terminating panels
• Media converters and protocol gateways
• Maintenance spares for legacy multimode equipment

Specifications
