10M 1x9 FC TX Optical Transceiver, 1310nm, 40km

Overview

The FT-10M-19 is a long-reach 10 Mbps 1x9 optical transceiver module in the TX variant (FT-ST134–F*/T), built for single-mode fiber at 1310 nm. Its 40 km reach carries one-way data feeds and monitoring traffic from remote sites back to the control center. The threaded FC connector locks the fiber in place, resisting vibration in industrial settings. Supply options are 3.3 V or 5 V, and the host interface uses LVTTL/TTL signal levels. The module comes in commercial (0 to 70 °C) and industrial (-40 to 85 °C) temperature grades. The through-hole 1x9 package fits standard board footprints for straightforward integration.

Key Features

• 10 Mbps over single-mode 1310 nm fiber, 40 km reach
• TX variant, series model FT-ST134–F*/T
• Vibration-resistant threaded FC coupling
• 3.3 V or 5 V supply options
• LVTTL/TTL host interface
• Commercial and industrial grades

Applications

• Remote monitoring traffic backhaul
• One-way broadcast distribution over long distance
• Utility and substation data links
• Inter-site fiber connections

Specifications
