10M 1x9 FC Optical Transceiver, 1310nm, 20km

Overview

The FT-10M-12 is a 10 Mbps 1x9 optical transceiver module with a threaded FC connector, built for single-mode fiber at 1310 nm. The screw-type coupling holds the connection firmly in place, which suits vibration-prone industrial environments. With a 20 km reach, the module extends 10 Mbps Ethernet links between buildings or across factory floors. It follows series model FT-ST132-F* and draws power from either 3.3 V or 5 V. Signal levels are LVTTL/TTL, so host boards need no level translation. Commercial and industrial temperature grades (0 to 70 °C and -40 to 85 °C) cover both office and outdoor installations. The 1x9 package keeps mounting simple on through-hole boards.

Key Features

• 10 Mbps over single-mode 1310 nm fiber, 20 km reach
• Threaded FC connector with secure screw coupling
• Series model FT-ST132-F*
• Dual supply: 3.3 V or 5 V
• LVTTL/TTL signal levels, no level translation needed
• Wide temperature grades: 0 to 70 °C and -40 to 85 °C

Applications

• 10 Mbps fiber links between buildings
• Industrial automation with vibration exposure
• Factory floor data collection networks
• Legacy equipment service and replacement

Specifications

Contact

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
