1 / 510G SFP+ 1550nm 10km SDH/PDH Transceiver
F-tone Networks 10G SFP+ for SDH/PDH, 1550nm, 10km single-mode reach, EML laser with PIN receiver, -3 to +4dBm output, -15dBm sensitivity, LC, fixed rate.
- Form Factor
- SFP+
- Data Rate
- 10G
- Wavelength
- 1550nm
- 光器件
- EML/PIN
- 发光范围
- -3~+4dBm
- 收端灵敏度
- -15dBm
Reference model FT-SFPPLUS-10G-LR-1550 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Form Factor | SFP+ |
|---|---|
| Data Rate | 10G |
| Wavelength | 1550nm |
| 光器件 | EML/PIN |
| 发光范围 | -3~+4dBm |
| 收端灵敏度 | -15dBm |
| 接口 | LC |
| 工作温度范围 | 商业级/工业级/军品级可选 |
| Distance | 10KM |
| 多速率兼容 | N |
Product details
A 1550nm SFP+ intended for SDH/PDH transport over 10km of single-mode fiber. The EML transmitter delivers -3 to +4dBm and the PIN receiver is rated at -15dBm. The source lists it as fixed-rate, not multi-rate. It uses an LC port and can be ordered in commercial, industrial or military temperature grade.
Key Features
- 1550nm, 10km
- EML/PIN
- -3 to +4dBm output
- -15dBm sensitivity
- Fixed rate; LC
Applications
- SDH/PDH transport links
- Telecom access networks
- Short carrier point-to-point spans
Specifications
| Parameter | Value |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 10G |
| Wavelength | 1550nm |
| Laser / Detector | EML/PIN |
| Output Power | -3~+4dBm |
| Receiver Sensitivity | -15dBm |
| Connector | LC |
| Operating Temperature | Commercial, industrial or military grade (selectable) |
| Reach | 10KM |
| Multi-rate Support | No |
