10G OTU/OEO Multi-Service Card, 4x10G, 8 SFP+

As an OTU/OEO service board, this card regenerates and converts 10G clients for WDM systems. Capacity is 4 x 10G bidirectional or 8 x 10G unidirectional across 8 SFP+ ports with CDR. Line wavelengths cover CWDM 1271-1611 nm and C-band DWDM at 100 GHz or 50 GHz. On the client side it accepts SDH at STM-16 and STM-64, SONET at OC-48 and OC-192, PDH, Ethernet in FE, GE and 10GE form, 1G to 10G rates, CPRI options 1 through 7, POS, FICON and ESCON. 3R processing (re-amplify, retime, reshape) is built in, with Web or NetViver management. The board is 156 x 20 x 225 mm and draws under 18 W.

Key Features

• 4 x 10G bidirectional or 8 x 10G unidirectional
• 8 x SFP+ ports with CDR, 1G-10G multi-rate
• CWDM 1271-1611 nm and DWDM C-band (100/50 GHz)
• 3R: re-amplifying, retiming, re-shaping
• DDM monitoring; Web / NetViver management
• Power <18 W; -10 to 70 °C operating

Applications

• Multi-service access on CWDM/DWDM systems
• 10G wavelength conversion and regeneration
• SDH, Ethernet and CPRI transport over WDM

Specifications

Ordering References

Model and part numbers for ordering reference:
