100BASE SFP 1550nm Transceiver, 155Mbps, 100km ZX Reach

Overview

The FT-SFP-FE55-ZX100 is a 100BASE SFP transceiver built for long-reach Fast Ethernet transmission at 155 Mbps. Its 1550nm DFB laser and PIN receiver deliver up to 100km over single-mode fiber through a duplex LC connector, with transmit power of -4.0 to +2.0dBm and receive sensitivity better than -34.0dBm. The module is MSA compliant and is available in commercial, industrial, and military temperature grades. It is suited to telecom access, metro, and enterprise backbone links that need dependable 100km single-span performance.

Key Features

• 155 Mbps data rate, 100BASE SFP form factor
• 1550nm DFB transmitter with PIN receiver
• Transmit power -4.0 to +2.0dBm; receive sensitivity better than -34.0dBm
• 100km reach over single-mode fiber with duplex LC connector
• MSA compliant; commercial, industrial, and military temperature grades available
• Compatible with Adva, Extreme, HP, and NEC platforms

Applications

• Long-haul Fast Ethernet transport
• Metro and access network backbones
• Carrier aggregation links
• Enterprise campus backbones

Specifications
