100BASE-LX SFP 1310nm Transceiver, 155Mbps, 20km Reach

Overview

The FT-SFP-FE31-LX20 is a 100BASE-LX SFP transceiver for 1310nm Fast Ethernet links at 155 Mbps. Its 1310nm FP laser and PIN receiver deliver 20km over single-mode fiber through a duplex LC connector, with transmit power of -14.0 to -8.0dBm and receive sensitivity better than -32.0dBm. The module is MSA compliant and comes in commercial, industrial, and military temperature grades. It suits enterprise, campus, and access networks that need cost-effective 20km optical connectivity. The module is designed for plug-and-play installation in standard Fast Ethernet switches and access equipment.

Key Features

• 155 Mbps data rate, 100BASE-LX SFP form factor
• 1310nm FP transmitter with PIN receiver
• Transmit power -14.0 to -8.0dBm; receive sensitivity better than -32.0dBm
• 20km reach over single-mode fiber with duplex LC connector
• MSA compliant; commercial, industrial, and military temperature grades available
• Compatible with Adva, HP, and NEC platforms

Applications

• Enterprise campus networks
• Short-to-mid-reach access links
• FTTx aggregation
• Industrial Ethernet networks

Specifications
