FT-10G-40KM product image - F-tone Networks

1 / 2

MODEL · FT-10G-40KM

10GBASE 100GHz DWDM XENPAK 40km Transceiver

F-tone Networks FT-10G-40KM: 10G XENPAK DWDM transceiver on the 100 GHz grid with 40 km reach, LC connector, -40 to +85 C range, for metro aggregation.

17: DXPK-10G17-40
18: DXPK-10G18-40
19: DXPK-10G19-40
20: DXPK-10G20-40
21: DXPK-10G21-40
22: DXPK-10G22-40

Reference model FT-10G-40KM in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓

Specifications

Technical parameters

17	DXPK-10G17-40
18	DXPK-10G18-40
19	DXPK-10G19-40
20	DXPK-10G20-40
21	DXPK-10G21-40
22	DXPK-10G22-40
23	DXPK-10G23-40
24	DXPK-10G24-40
25	DXPK-10G25-40
26	DXPK-10G26-40
27	DXPK-10G27-40
28	DXPK-10G28-40
29	DXPK-10G29-40
30	DXPK-10G30-40
31	DXPK-10G31-40
32	DXPK-10G32-40
33	DXPK-10G33-40
34	DXPK-10G34-40
35	DXPK-10G35-40
36	DXPK-10G36-40
37	DXPK-10G37-40
38	DXPK-10G38-40
39	DXPK-10G39-40
40	DXPK-10G40-40
41	DXPK-10G41-40
42	DXPK-10G42-40
43	DXPK-10G43-40
44	DXPK-10G44-40
45	DXPK-10G45-40
46	DXPK-10G46-40
47	DXPK-10G47-40
48	DXPK-10G48-40
49	DXPK-10G49-40
50	DXPK-10G50-40
51	DXPK-10G51-40
52	DXPK-10G52-40
53	DXPK-10G53-40
54	DXPK-10G54-40
55	DXPK-10G55-40
56	DXPK-10G56-40
57	DXPK-10G57-40
58	DXPK-10G58-40
59	DXPK-10G59-40
60	DXPK-10G60-40
61	DXPK-10G61-40
1550	155M-10.3125G \| 1550 \| 40 \| SMF \| LC \| -40~+85℃
Type	Bite Rate \| Wavelength of Laser(nm) \| Transmission Range(km) \| Fiber Type \| Connector \| Temperature
DWDM	155M-10.3125G \| 50Ghz DWDM \| 40 \| SMF \| LC \| -40~+85℃
Part No.	Data Rate (Gbps)
DXPK-10GXX-40	≤ 10
DXPK-10GXX-80	≤ 10
Channel	Part No.

Overview

Product details

Overview

The FT-10G-40KM is a DWDM transceiver in the original XENPAK package, keeping first-generation 10G routers and switches on DWDM transport without a chassis refresh. It runs 155 Mbps to 10.3125 Gbps on the 100 GHz DWDM grid and reaches 40 km over single-mode fiber through a duplex LC connector, with 45 channel options (DXPK-10G17-40 to DXPK-10G61-40). The module tolerates -40 to +85 degrees C, so it survives unconditioned cabinets and outdoor enclosures, and a fixed-wavelength 1550 nm variant is available for single-channel links.

Key Features

XENPAK form factor for 10G DWDM on legacy 10G platforms
Multi-rate 155 Mbps to 10.3125 Gbps on 100 GHz DWDM grid
40 km reach over SMF, duplex LC connector
45 channel options (DXPK-10G17-40 to DXPK-10G61-40); 1550 nm fixed version available
Operating temperature -40 to +85 C

Applications

XENPAK-based router and switch DWDM uplinks
Metro 40 km transport
Outdoor cabinet deployments
Legacy 10G network upgrades

Specifications

Parameter	Value
Form Factor	XENPAK
Data Rate	155 Mbps to 10.3125 Gbps
Grid	100 GHz DWDM
Max Distance	40 km
Fiber Type	SMF
Connector	LC
Operating Temperature	-40 to +85 C
Channels	ITU 17 to 61 (45 channels), DXPK-10G17-40 to DXPK-10G61-40
Fixed-Wavelength Version	1550 nm, 40 km, also available

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: Betty — betty@f-tone.com · WhatsApp: +86 17360698946; Una — una@f-tone.com · WhatsApp: +86 17761163895
