FT-100670 10/100/1000Base-TX to 1000Base-LX BIDI Gigabit Media Converter 40km

The FT-100670 is a single-fiber bidirectional (BIDI) gigabit media converter reaching 40 km on single-mode fiber. It uses a TX 1550 nm / RX 1310 nm wavelength pairing over SC connectors, so one fiber strand carries both directions of traffic. The card-format unit measures 112.8 x 77.2 x 23 mm and integrates two 1000Base-X SC ports with a 10/100/1000M RJ45 port, supporting 10/100/1000 Mbps access and 1000M full-duplex fiber operation. It consumes under 3 W from a built-in 5–12 V DC supply and delivers MTBF above 50,000 hours. Compliance with IEEE 802.3, 802.3u and 802.3z is standard, with commercial, industrial and military temperature grades offered as options.

Key Features

• Single-fiber BIDI design: TX 1550 nm / RX 1310 nm over SC connectors
• 40 km reach on single-mode 9/125 µm fiber
• Two 1000Base-X SC ports plus one 10/100/1000M RJ45 port
• 10/100/1000 Mbps access mode; 1000M full-duplex fiber operation
• Power consumption below 3 W; 5–12 V DC input with built-in supply
• IEEE 802.3 / 802.3u / 802.3z compliant; MTBF above 50,000 hours

Applications

• Long-haul campus, metro and rural access links
• Telecom backhaul and point-to-point transmission
• Utility and transportation network corridors

Specifications
