10G SR 850nm 300m Multimode Camera-Type Transceiver

Overview

The FT-10G-300M-850 is a 10G short-reach optical transceiver in camera-type form factor, built for board-mounted integration rather than pluggable cages. At only 12 mm tall with a full metal housing, it solders onto equipment boards where space and EMI shielding matter, such as industrial cameras and embedded vision systems. The 850 nm transmitter drives up to 300 m over multimode fiber through a duplex LC interface at 10.3125 Gbps. Surface-mount I/O pins are laid out for high-speed signal integrity, the anti-vibration design suits moving equipment, and the module operates down to -40 C on a single +3.3 V supply.

Key Features

• Camera-type 10-pin board-mount form factor; pinout compatible with STRATOS mounting layouts
• 12 mm low profile with full metal housing and anti-vibration design
• 10.3125 Gbps at 850 nm (840 to 860 nm), up to 300 m over multimode fiber
• Duplex LC interface; single +3.3 V supply
• RX data signal detection for link diagnostics
• Operating temperature rated from -40 C; storage -55 to +85 C

Applications

• Industrial cameras and machine vision systems
• Board-level 10G optical interconnects
• 10GBase-SR switch uplinks
• Fibre Channel and SONET/SDH equipment

Specifications
