1-Channel Video and Return Data Fiber Optic Multiplexer, 20 km SM

The FT-20KM-97 from F-tone Networks is a fiber optic multiplexer that carries one channel of uncompressed composite video together with one return data channel over a single single-mode fiber, with a reach of up to 20 km on 1310/1550 nm wavelengths and a 12 dB optical power budget. Video is encoded at 8-bit resolution through a 75Ω BNC interface and supports PAL, NTSC and SECAM systems. The return path handles serial data from DC to 115.2 Kbps with RS-485 (2-wire/4-wire), RS-232, RS-422 and contact closure at a 10E-9 bit error rate, suited to PTZ camera control. The unit works as a standalone module or as a card in a 19-inch rack chassis.

Key Features

• One composite video channel over single-mode fiber, 8-bit uncompressed digital encoding
• One return data channel for RS-485, RS-232 and RS-422 serial control, DC to 115.2 Kbps
• Data-channel bit error rate 10E-9, suited to PTZ and device control
• 20 km single-mode reach; 1310/1550 nm; 12 dB optical power budget
• PAL, NTSC and SECAM compatible; 75Ω BNC video interface
• Standalone or 19-inch rack-card installation; LED status indication

Applications

• PTZ camera control over surveillance fiber links
• Traffic and highway monitoring networks
• Industrial closed-circuit television systems
• Public security surveillance

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
