10G XFP DWDM C49 1538.19nm 80km 100GHz
DWDM XFP locked to 1538.19nm (C49), 80km SMF, EML out and APD in, 11.1Gbps, under 1.5W, DOM, duplex LC; brand-compatible codes. Supplied by F-tone Networks.
- Part Number
- XFP-DW10G49-80C
- Manufacturer
- F-tone
- Form Factor
- XFP
- Data Rate
- 11.1Gbps
- Wavelength
- 1538.19nm
- Max Distance
- 80km
Reference model FT-XFP-DW10G49-80C in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Part Number | XFP-DW10G49-80C |
|---|---|
| Manufacturer | F-tone |
| Form Factor | XFP |
| Data Rate | 11.1Gbps |
| Wavelength | 1538.19nm |
| Max Distance | 80km |
| Connector Type | 双工 LC |
| Transmitter Type | DWDM EML |
| Cable Type | 单模(SMF) |
| Receiver Type | APD |
| TX Power | 0~+4.0dBm |
| RX Sensitivity | < -23.0dBm |
| Protocol | MSA Compliant |
| Operating Temperature | 商业级/工业级/军品级可选 |
| Alcatel-Lucent Compatible | XFP-10G-DWDM-49 |
| Ciena Compatible | 130-4903-900-49 |
| 戴尔兼容型号 | GP-XFP-W49 |
| Extreme Compatible | 10249 |
| 惠普兼容型号 | JG226A-49 |
| Model Name | C49 XFP-LX-SM1538.19 |
| Connector | LC Duplex |
| Power Consumption | <1.5W |
| DOM | Support |
| Protocols | SFP+ MSA Compliant, CPRI, eCPRI |
Product details
Locked to 1538.19 nm for channel C49, this DWDM XFP spans 80 km of SMF. Optical chain: EML out at 0 to +4.0 dBm, APD in with sensitivity below -23.0 dBm. Rated 11.1 Gbps. Mechanically a standard XFP with a duplex LC port; electrically under 1.5 W with DOM telemetry. Switch and transport brands each get a matching code.
Key Features
- Channel C49, 1538.19 nm
- Spans 80 km of SMF
- EML out 0~+4.0 dBm; APD in < -23.0 dBm
- Rate 11.1 Gbps
- <1.5 W, DOM, duplex LC
- Selectable temperature grade
Applications
- DWDM metro and regional transport
- 10G Ethernet and SDH over DWDM
- Mixed-vendor DWDM networks
Specifications
| Parameter | Value |
|---|---|
| Form Factor | XFP |
| Data Rate | 11.1 Gbps |
| Wavelength | 1538.19nm |
| Grid | 100 GHz DWDM |
| Max Distance | 80 km |
| Fiber | Single-mode (SMF) |
| Connector | LC Duplex |
| Transmitter Type | DWDM EML |
| Receiver Type | APD |
| TX Power | 0~+4.0 dBm |
| RX Sensitivity | < -23.0 dBm |
| Power Consumption | <1.5 W |
| DOM | Supported |
| Protocols | MSA compliant; SFP+ MSA Compliant, CPRI, eCPRI (as listed) |
| Operating Temperature | Commercial / industrial / military grade optional |
| Compatible Brands | Adva / Alcatel / Ciena / Dell / Extreme / HP / HPE / Nec |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| XFP-DW10G49-80C | 10G XFP DWDM 1538.19nm, 80 km |
| Model name | C49 XFP-LX-SM1538.19 |
| Alcatel-Lucent compatible | XFP-10G-DWDM-49 |
| Ciena compatible | 130-4903-900-49 |
| Dell compatible | GP-XFP-W49 |
| Extreme compatible | 10249 |
| HP compatible | JG226A-49 |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
