10G XFP DWDM C52 1535.82nm 80km 100GHz
Channel C52 XFP for 80km DWDM hops at 1535.82nm, EML transmit and APD receive, rates to 11.1Gbps, DOM, duplex LC, less than 1.5W. Supplied by F-tone Networks.
- Part Number
- XFP-DW10G52-80C
- Manufacturer
- F-tone
- Form Factor
- XFP
- Data Rate
- 11.1Gbps
- Wavelength
- 1535.82nm
- Max Distance
- 80km
Reference model FT-XFP-DW10G52-80C in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Part Number | XFP-DW10G52-80C |
|---|---|
| Manufacturer | F-tone |
| Form Factor | XFP |
| Data Rate | 11.1Gbps |
| Wavelength | 1535.82nm |
| Max Distance | 80km |
| Connector Type | 双工 LC |
| Transmitter Type | DWDM EML |
| Cable Type | 单模(SMF) |
| Receiver Type | APD |
| TX Power | 0~+4.0dBm |
| RX Sensitivity | < -23.0dBm |
| Protocol | MSA Compliant |
| Operating Temperature | 商业级/工业级/军品级可选 |
| Alcatel-Lucent Compatible | XFP-10G-DWDM-52 |
| Ciena Compatible | 130-4903-900-52 |
| 戴尔兼容型号 | GP-XFP-W52 |
| Extreme Compatible | 10252 |
| 惠普兼容型号 | JG226A-52 |
| Model Name | C52 XFP-LX-SM1535.82 |
| Connector | LC Duplex |
| Power Consumption | <1.5W |
| DOM | Support |
| Protocols | SFP+ MSA Compliant, CPRI, eCPRI |
Product details
An 80 km hop at 1535.82 nm is the job of this channel C52 XFP. Inside, a DWDM EML handles transmission and an APD handles reception, giving 0 to +4.0 dBm launch power and sensitivity under -23.0 dBm at rates to 11.1 Gbps. It plugs in with duplex LC fiber, reports DOM data and needs less than 1.5 W. Grade choices cover commercial, industrial and military temperature ranges.
Key Features
- C52 / 1535.82 nm
- 80 km hop on SMF
- EML transmit, APD receive
- Up to 11.1 Gbps
- DOM, duplex LC, <1.5 W
- Commercial to military grade options
Applications
- DWDM metro and regional transport
- 10G Ethernet and SDH over DWDM
- Mixed-vendor DWDM networks
Specifications
| Parameter | Value |
|---|---|
| Form Factor | XFP |
| Data Rate | 11.1 Gbps |
| Wavelength | 1535.82nm |
| Grid | 100 GHz DWDM |
| Max Distance | 80 km |
| Fiber | Single-mode (SMF) |
| Connector | LC Duplex |
| Transmitter Type | DWDM EML |
| Receiver Type | APD |
| TX Power | 0~+4.0 dBm |
| RX Sensitivity | < -23.0 dBm |
| Power Consumption | <1.5 W |
| DOM | Supported |
| Protocols | MSA compliant; SFP+ MSA Compliant, CPRI, eCPRI (as listed) |
| Operating Temperature | Commercial / industrial / military grade optional |
| Compatible Brands | Adva / Alcatel / Ciena / Dell / Extreme / HP / HPE / Nec |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| XFP-DW10G52-80C | 10G XFP DWDM 1535.82nm, 80 km |
| Model name | C52 XFP-LX-SM1535.82 |
| Alcatel-Lucent compatible | XFP-10G-DWDM-52 |
| Ciena compatible | 130-4903-900-52 |
| Dell compatible | GP-XFP-W52 |
| Extreme compatible | 10252 |
| HP compatible | JG226A-52 |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
