1 / 36MODEL · FT-SFP-FE35-BX20
155M BiDi SFP 1310/1550nm 20km Simplex LC Module
F-tone Networks FT-SFP-FE35-BX20: 155Mbps BiDi SFP with TX1310/RX1550nm over single-mode fiber up to 20km, simplex LC connector, MSA compliant Ethernet module.
Optical TransceiversIndustrial & Enterprise SwitchesIndustrial CommunicationAccessoriesCompatible: AdvaCompatible: HPCompatible: Nec
- Part Number
- SFP-FE35-BX20
- Manufacturer
- F-tone
- Form Factor
- SFP
- Data Rate
- 155Mbps
- Wavelength
- TX1310nm/RX1550nm
- Max Distance
- 20km
Reference model FT-SFP-FE35-BX20 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| Part Number | SFP-FE35-BX20 |
|---|---|
| Manufacturer | F-tone |
| Form Factor | SFP |
| Data Rate | 155Mbps |
| Wavelength | TX1310nm/RX1550nm |
| Max Distance | 20km |
| Connector Type | 单工 LC |
| Transmitter Type | 1310nm FP |
| Cable Type | 单模(SMF) |
| Receiver Type | PIN |
| TX Power | -14.0~-8.0dBm |
| RX Sensitivity | <-32.0dBm |
| Protocol | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
| Operating Temperature | 商业级/工业级/军品级可选 |
| Standard | IEEE 802.3 10BASE-T Ethernet. |
| Data Transfer Rate | Ethernet: 10Mbps (half-dupelx), 20Mbps (full-duplex). |
| Network Cables | 10Base-T: 2-pair UTP Cat 3, 4, 5 up to 100 meters. |
| Number of Ports | 8 x 10/100Mbps auto-MDIX RJ-45 ports with 8 PoE enabled ports. |
| PoE power on RJ-45 | Power +: pin 3 & pin 6 ; Power –: pin 1 & pin 2. |
| Power Supply | Input: 100V ~ 240VAC, 50Hz ~ 60Hz. |
| Power Consumption | 8.0W ( max with no PD device connected). |
| Temperature | Operation: 0C ~ 40C or 32F ~ 104F. |
| Humidity | Relative Humidity: 5% - 95%. |
| Dimensions | 210mm W x 170mm D x 44.3mm H. |
| EMI | FCC Class B, CE Mark Class B. |
| Safety | 110VAC to 240VAC power supply UL listed. |
| RAM buffer | 2.75Mb bytes per device. |
| Filtering Address Table | 4K entries per device. |
| Packet Filtering Forwarding Rate | 10Mbps Ethernet: 14,880/pps. |
| MAC address Learning | Automatic update. |
| Transmission Method | Store – and – Forward. |
| FT-POE3608-XX | 8-Port 10/100M POE Switch with 1-Port Giga Combo SFP Slot |
| F:IEEE802.3af | 3: 30W |
| Product Specifications | Network Protocol and Standard |
| 24+2-Port 10/100M PoE Switch | 24-port 10/100PoE switch with 2 1000 Base _ T Port + 2 Giga SFP Port (GS) |
| MAC Address Table | 4K |
| Forwarding Rate | 14,880pps 10M /148,880pps 100M /1,488,0001000M |
| VLANs | Support |
| Built-in RAM | 2.75Mb |
| Support packet length | 1536 Bytes |
| Interface Options | PoE Power Out & Power Input |
| RJ-45 x 24 | 1000Base-T |
| RJ-45 X 2 | 1000Base-T support based on SFP/LC |
| SFP X 2 | (24+2-Port 10/100M PoE Switch only) |
| LED Indicators | Per Port: 10/100, Link /ACT |
| PoE Act /Status | Power Consumption |
| Certification | FCC /CE /RoHS |
| FT-POE3624-XX | 24-Port 10/100M POE Switch |
| FT-POE3624M-XX | 24-Port 10/100M Managed POE Switch with 2-Port Giga Combo SFP Slot |
| FT-POE3616-XX | 16-Port 10/100M POE Switch |
| FT-POE3616M-XX | 16-Port 10/100M Managed POE Switch with 2-Port Giga Combo SFP Slot |
Overview
Product details
Overview
The FT-SFP-FE35-BX20 is a 155Mbps bidirectional (BiDi) SFP module built for Fast Ethernet links over a single strand of single-mode fiber. It transmits at 1310nm and receives at 1550nm through a simplex LC connector, reaching up to 20km. Combining a 1310nm FP laser transmitter with a PIN receiver sensitive to better than -32.0 dBm, the MSA compliant module delivers a cost-effective single-fiber option for Fast Ethernet deployments.
Key Features
- 155Mbps data rate for Fast Ethernet links
- BiDi operation: TX 1310nm / RX 1550nm over one single-mode fiber
- Simplex LC connector; 1310nm FP laser transmitter with PIN receiver
- Transmit power -14.0 to -8.0 dBm; receive sensitivity better than -32.0 dBm
- Link distance up to 20km on single-mode fiber
- MSA compliant SFP form factor
Applications
- Single-fiber Fast Ethernet access and aggregation links
- Telecom and enterprise point-to-point connections up to 20km
- Fiber-scarce routes where BiDi single-strand operation saves fiber
Specifications
| Parameter | Value |
|---|---|
| Part Number | FT-SFP-FE35-BX20 |
| Form Factor | SFP |
| Data Rate | 155Mbps |
| Wavelength | TX1310/RX1550 nm |
| Max Distance | 20km |
| Fiber Type | Single-mode |
| Connector | Simplex LC |
| Transmitter | 1310nm FP |
| Receiver | PIN |
| TX Power | -14.0 to -8.0 dBm |
| RX Sensitivity | < -32.0 dBm |
| Protocol | MSA compliant |
Contact
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
Compatibility
Compatible platforms
AdvaHPNec
