100G QSFP28 LR4 10km Optical Transceiver

Overview

The FT-Q28-100G-LR4 is a 100G QSFP28 LR4 optical transceiver for 10 km single-mode fiber links. It transmits four LAN WDM wavelengths in the 1310 nm band through a duplex LC connector, reaching data centers, enterprise backbones and carrier access networks that need reliable 10 km reach. Transmit power spans -4.3 to +4.5 dBm with receiver sensitivity better than -10.6 dBm, and digital diagnostics are supported for live link monitoring. The module follows IEEE 802.3ba 100GBASE-LR4 and the QSFP28 MSA. Commercial, industrial and extended temperature grades are available to match deployment conditions.

Key Features

• 100G QSFP28 LR4, 10 km over single-mode fiber
• Four LAN WDM DFB wavelengths in the 1310 nm band
• Duplex LC connector with DDM support
• TX -4.3 to +4.5 dBm; RX sensitivity better than -10.6 dBm
• IEEE 802.3ba 100GBASE-LR4 and QSFP28 MSA compliant
• Commercial, industrial and extended temperature grades

Applications

• Data center interconnects up to 10 km
• Enterprise and campus backbone links
• Carrier metro and access networks

Specifications
