100G QSFP28 Passive Direct Attach Copper Cable

Overview

The FT-QSFP28-100G-11 is a 100G passive direct attach copper cable for short-reach QSFP28 interconnects. It is available in 1 m, 3 m and 5 m lengths, with 30 AWG cable for the 1 m and 3 m versions and 26 AWG for the 5 m version. Configurations cover QSFP28 to QSFP28 straight connections and QSFP28 to 4xSFP28 breakout links. As a passive copper design it draws power only through the host PHY, keeping latency low and cost below optical alternatives. It follows standard QSFP28 and SFF electrical interfaces and suits server, switch and storage connections inside and between adjacent racks.

Key Features

• 100 Gb/s aggregate over 4 x 25G electrical lanes
• Passive copper twinax construction with no active components
• Lengths 1 m, 3 m and 5 m; 30 AWG for 1/3 m, 26 AWG for 5 m
• QSFP28 to QSFP28 and QSFP28 to 4xSFP28 configurations
• Low latency and low power for short-reach links

Applications

• Top-of-rack switch to server connections
• In-rack and adjacent-rack switch interconnects
• Storage array and aggregation links

Specifications
