1 / 2MODEL · FT-CFP2-100G-LR4-2
100G CFP2 LR4 Single Rate 10km Module
F-tone Networks FT-CFP2-100G-LR4-2: 100G CFP2 LR4 single-rate optical module, 111.8 Gbps aggregate, 10 km over single-mode fiber, LWDM, duplex LC, 6 W, DDMI.
- 900
- mVpp
- Part No.
- Data Rate
- Laser
- Fiber Type
- Distance
- Optical Interface
- Temp
- DDMI
- CFP2-100G-LR4
- 103.1~111.8Gbps
Reference model FT-CFP2-100G-LR4-2 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| 900 | mVpp |
|---|---|
| Part No. | Data Rate |
| Laser | Fiber Type |
| Distance | Optical Interface |
| Temp | DDMI |
| CFP2-100G-LR4 | 103.1~111.8Gbps |
| LWDM | SMF |
| 10km | LC |
| -5~70C | Y |
| Storage Temperature | TS |
| Supply Voltage | VCC |
| Operating Relative Humidity | FH |
| Operating Case Temperature | TC |
| Power Supply Voltage | VCC |
| 3.13 | 3.3 |
| Power Supply Current | ICC | 1.8 |
| Maximum Power Dissipation | PD |
| Aggregate Bit Rate | BRAVE |
| Lane Bit Rate | BRLANE |
| Transmission Distance | TD |
| km | Over SMF |
| Center Wavelength Lane 0 | λ0 |
| 1294.53 | 1295.56 |
| Center Wavelength Lane 1 | λ1 |
| 1299.02 | 1300.05 |
| Center Wavelength Lane 2 | λ2 |
| 1303.54 | 1304.58 |
| Center Wavelength Lane 3 | λ3 |
| 1308.09 | 1309.14 |
| Total Launch Power, 100GE | PALL | – | – | 10.5 | dBm | 1 |
| Average Launch Power per Lane, 100GE | PTX_LANE | -4.3 | – | 4.5 | dBm | 1 |
| OMA per Lane, 100GE | OMA | -1.3 | – | 4.5 | dBm | 1 |
| OMA–TDP per Lane, 100GE | OMA_TDP |
| Difference in launch power between lanes | PTX_DELTA_LANE |
| Average Output Power (Laser Turn off) | P0UT-OFF |
| Side Mode Suppression Ratio | SMSR |
| Extinction Ratio, 100GE | ER |
| Transmitter and Dispersion Penalty | TDP | – | – | 2.2 | dB | 2 |
| Optical Return Loss Tolerance | ORLT |
| Optical Eye Mask, 100GE | Compliant with IEEE 802.3bm | 2 |
| Average Rx Power per Lane, 100GE | PRX _LANE |
| -10.6 | 4.5 |
| dBm | 3 |
| OMA Sensitivity per Lane, 100GE | POMA_LANE | – | – | -8.6 | dBm | 3 |
| Receiver Overload | PIN-OL |
| Reflectance | Ref |
| LOS Assert per lane | LOSA |
| LOS De-assert | LOSD |
| LOS Hysteresis | LOSH | 0.5 | 4 | dB |
| Differential Data Input Amplitude | VIN,P-P |
| Differential Termination Mismatch | – | – | 10 | % |
| Tx_Disable | Normal Operation | VIL | -0.3 | – | 0.8 | V |
| Laser Disable | VIH |
| Differential Data Output Amplitude | VOUT,P-P |
| Differential Termination Mismatch（1MHZ） | – | – | 10 | % |
| Output Rise/Fall Time, 20%~80% | TR |
| Rx_LOS | Normal Operation | VOL | – | – | 0.2 | V |
| Lose Signal | VOH |
| Temperature | 0 to 70 | ±3 | ºC | Internal |
| Voltage | 0 to VCC | 0.1 | V | Internal |
| Tx Bias Current Per Lane | 0 to 100 | 10% | mA | Internal |
| Tx Output Power Per Lane | -4.3 to 4.5 | ±3 | dBm | Internal |
| Rx Power (Each Lane) | -10.6to 4.5 | ±3 | dBm | Internal |
| 0~70C | Y |
| 111.8 | Gb/s |
| 27.95 | Gb/s |
| Total Launch Power, OTU4 | PALL |
| 8.9 | 1 |
| Average Launch Power per Lane, OTU4 | PTX_LANE | -2.5 | – | 2.9 | dBm | 1 |
| Extinction Ratio, OTU4 | ER |
| Optical Eye Mask, OTU4 | {0.25, 0.4, 0.45, 0.25, 0.28, 0.4} Compliant with ITU-T G.959.1 | 2 |
| Average Rx Power per Lane, OTU4 | PRX_AVE_LANE | -8.8 | 2.9 | dBm |
| Sensitivity per Lane, OTU4 | PRX_AVE_LANE | – | – | -10.3 | dBm | 4 |
| Damage Threshold | Pdamage |
| Receiver Reflectance | FL |
Overview
Product details
Overview
The FT-CFP2-100G-LR4-2 is a single-rate 100G CFP2 transceiver for 10 km links over single-mode fiber. Four LWDM lanes in the 1295 to 1310 nm band deliver 111.8 Gbps aggregate through a duplex LC connector, while the compact CFP2 footprint frees space on dense line cards. With maximum power dissipation of only 6 W, it eases thermal budgets in crowded chassis. The module runs from −5 to 70 °C and includes digital diagnostics monitoring of temperature, voltage, bias current and optical power per lane. It is a straightforward, low-power choice for 100G Ethernet connections between data centers and campus buildings.
Key Features
- Single-rate 100G operation at 111.8 Gbps aggregate
- Compact CFP2 form factor
- 10 km over single-mode fiber, duplex LC
- Low power: 6 W maximum dissipation
- Digital diagnostics monitoring per lane
- −5 to 70 °C operating temperature
Applications
- Data center 100G server and switch interconnects
- Campus backbone links
- Enterprise core upgrades
- Cost-sensitive 10 km 100GE deployments
Specifications
| Part Number | FT-CFP2-100G-LR4-2 |
| Form Factor | CFP2 |
| Data Rate | 111.8 Gb/s (single rate) |
| Transmitter | 4 × LWDM, 1295–1310 nm |
| Center Wavelengths (typical) | 1295.56 / 1300.05 / 1304.58 / 1309.14 nm |
| Fiber Type | Single-mode fiber (SMF) |
| Transmission Distance | 10 km |
| Optical Connector | Duplex LC |
| Operating Temperature | −5 to 70 °C |
| Supply Voltage | 3.3 V |
| Maximum Power Dissipation | 6 W |
| Digital Diagnostics | Yes (DDMI) |
