10G Symmetric EPON ONU SFP+, 1270nm TX / 1577nm RX, PR30

Symmetric 10G EPON subscribers use this SFP+ optic in their terminal equipment: it sends 10.3G upstream on 1270nm and takes 10.3G downstream on 1577nm. Launch power is rated +4.0 to +9.0dBm and sensitivity better than -28.5dBm, which together satisfy PR30 over spans as long as 20km. A single SC port connects the drop fiber. Standards cited are IEEE 802.3av plus the SFP+ MSA. Its title quotes -40 to 85 degrees C; the specification table instead offers selectable grades.

Key Features

• Symmetric 10.3G ONU
• TX 1270nm / RX 1577nm
• TX power +4.0 to +9.0dBm
• RX sensitivity < -28.5dBm
• PR30, 20km, SC connector
• IEEE 802.3av, SFP+ MSA

Applications

• Symmetric 10G business access over PON
• Mobile backhaul and small-cell sites on 10G EPON

Specifications

Ordering References

Model and part numbers for ordering reference:
