800G OSFP Passive DAC Cable 1.5m (8 x 100G PAM4, IHS Finned Top)

Overview

The FT-OSFP-800G-PC1-5M is a 1.5-meter (5ft) passive direct-attach copper cable that carries 800Gb/s between two OSFP ports using 8 lanes of 100G PAM4 signaling. Built on AWG 30 twinax with IHS finned-top OSFP connectors, it draws only 0.1W per end, making it a low-power, low-latency option for short 800G interconnects. It follows OSFP MSA, IEEE 802.3ck and CMIS v4.0, and targets 800GBASE-CR8 Ethernet as well as 800G InfiniBand NDR fabrics.

Key Features

• 800Gb/s aggregate over 8 x 100G PAM4 lanes
• Passive copper twinax design with maximum 0.1W power draw per end
• IHS finned-top OSFP connectors on both ends for thermal performance
• Compliant with OSFP MSA, IEEE 802.3ck, CMIS v4.0 and 800GBASE-CR8
• AWG 30 cable with PVC (OFNR) jacket, commercial 0 to 70°C rating

Applications

• 800G Ethernet top-of-rack to spine interconnects
• 800G InfiniBand NDR fabrics in AI and HPC clusters
• Data center racks needing low-latency short-reach 800G links
• Power-constrained deployments where passive DACs beat AOCs on efficiency

Specifications
