1.25G SFP Transceiver, 1310nm, 2km MMF, Gigabit Ethernet

The FT-SFP-1-25G-2KM-1310 is a 1250 Mb/s SFP transceiver with a 1310 nm FP laser, built for Gigabit Ethernet and single-lane Fibre Channel links. It provides up to 2 km of transmission over 50/125 μm OM3 multi-mode fiber through a duplex LC interface.

The hot-pluggable SFP module offers transmit power from -9 to -3 dBm with an extinction ratio of 9 dB, and receiver sensitivity of -19 dBm with -3 dBm saturation. It is a compact, cost-efficient optical link for short-reach enterprise and data center connections.

Key Features

• 1250 Mb/s; 1310 nm FP laser; up to 2 km over 50/125 μm OM3 multi-mode fiber
• Transmit center wavelength 1270 to 1360 nm; average power -9 to -3 dBm
• Extinction ratio 9 dB; receiver sensitivity -19 dBm; saturation -3 dBm
• Hot-pluggable SFP; duplex LC connector
• For Gigabit Ethernet and 1x Fibre Channel links

Applications

• Gigabit Ethernet enterprise links
• 1x Fibre Channel connections
• Data center short-reach interconnects

Specifications
