1.25G SFP 1310/1550nm BiDi 60km Single-Fiber Transceiver

Overview

The FT-SFP-BIDI-1310-14 is a 1.25 Gbps SFP transceiver that combines bidirectional WDM with a long 60 km reach on a single strand of single-mode fiber. Transmit traffic goes out at 1310 nm while receive traffic arrives at 1550 nm, and the link requires a partner module at the remote site with the mirrored pairing (TX 1550 nm / RX 1310 nm). The compact SFP form factor keeps power and slot consumption low, and hot-swap support means the module can be fitted into operating equipment. With one fiber doing the work of two, operators can stretch gigabit connectivity across rural or inter-city routes without doubling their fiber inventory. F-tone Networks supplies the module to the specifications for fiber-lean, long-distance links.

Key Features

• 1.25 Gbps data rate in the SFP form factor
• BiDi WDM on a single strand of single-mode fiber
• TX 1310 nm / RX 1550 nm; pairs with TX 1550 nm / RX 1310 nm at the far end
• Simplex LC/SC interface, 60 km rated reach
• Hot-swappable SFP housing for live installation
• Compact footprint with low power and slot usage

Applications

• Long-distance single-fiber Gigabit Ethernet links
• Rural and inter-city telecom backhaul
• Fiber-scarce regional point-to-point connections
• Carrier access networks with one available strand

Specifications
