10G/1.25G Asymmetric EPON OLT XFP, PRX30, 20km SC

An XFP optic for the OLT side of an asymmetric 10G EPON tree. It sends 10.3G downstream at 1577nm plus 1.25G at 1490nm, and receives a single 1.25G upstream at 1310nm, so both 10G/1G and standard EPON ONUs can share the fiber. Listed values include ODN class PRX30, transmit power of +3.0 to +7.0dBm, sensitivity below -31.0dBm, a 20km reach and an SC interface. It follows IEEE 802.3av and 802.3ah.

Key Features

• Asymmetric 10G down / 1.25G up operation
• Downstream 1577nm (10.3G) and 1490nm (1.25G)
• Upstream receiver at 1310nm (1.25G)
• TX +3.0 to +7.0dBm; RX sensitivity < -31.0dBm
• PRX30 power budget, 20km SMF, SC port
• IEEE 802.3av and IEEE 802.3ah

Applications

• Operators raising downstream capacity while keeping 1G upstream
• Residential FTTH deployments on XFP-based OLTs

Specifications

Ordering References

Model and part numbers for ordering reference:
