10G/1.25G Symmetric EPON OLT XFP, PR30, 20km SC

Packaged in XFP, this OLT module carries symmetric 10G EPON alongside 1.25G EPON. Its two transmitters operate at 1577nm (10.3G) and 1490nm (1.25G); its burst receivers take 1270nm (10.3G) and 1310nm (1.25G) upstream. The data sheet specifies PR30, 20km over single-mode fiber with an SC receptacle, launch power of +2.0 to +5.0dBm and +2.0 to +7.0dBm, and sensitivity of -28.0dBm and -29.78dBm. Standards listed are IEEE 802.3av and 802.3ah.

Key Features

• Symmetric 10G plus legacy 1.25G EPON in XFP
• Wavelengths 1577/1490nm out, 1270/1310nm in
• PR30 class, 20km reach
• Sensitivity < -28.0dBm (10G) and < -29.78dBm (1G)
• SC single-mode interface
• Temperature grade selectable

Applications

• Symmetric gigabit-plus services for business and residential users
• Smooth upgrade of XFP OLT platforms

Specifications

Ordering References

Model and part numbers for ordering reference:
